Product overview

Suitable for AC three-phase four wire and three-phase five wire systems, with a frequency of 50-60Hz, a rated voltage of 690V, and a rated working current of 250-5000A. It is a distribution equipment for auxiliary equipment in industrial, mining, enterprise, and high-rise buildings, especially suitable for the renovation of factories and old enterprises.

Characteristics of dense bus duct structure:

1) Strong heat dissipation capability

The dense bus duct is tightly adhered to both the phase and the outer shell, thus capable of withstanding significant electrical and thermal stresses. And it can quickly dissipate the heat generated by the conductive discharge, with a high current carrying capacity. The joint is fastened with insulated bolts and connected with double copper bars, effectively increasing the contact area of the joint and greatly reducing the temperature rise at the joint location.

2) New generation environmentally friendly products

The dense busbar trunking is wrapped with flame-retardant cross-linked polyethylene heat shrink tubing, which has strong insulation performance and does not emit toxic gases when exposed to fire.

3) Flexible wiring

The dense bus duct socket interface is flexible and convenient to set up, with a large number of sockets and strong universality. When adjusting the position of electrical equipment, there is no need to change the power supply system.
